- Nebulizer Top and Bottom (Nebulizer Cup) Assembly
- Inspiratory Valve Cap
- Mouthpiece with Valve
- Tubing
(Figure D)
Instructions For Use Figure D (0d806a34 E83d 4ce4 9da2 1630c49790a8 07)
Step 7: Remove the Nebulizer Top from the Nebulizer Cup by twisting the Nebulizer Top counter-clockwise, and then lifting off (See Figure E).
(Figure E)
Instructions For Use Figure E (0d806a34 E83d 4ce4 9da2 1630c49790a8 08)
Step 8: Place the Nebulizer Top on the clean paper or cloth towel by standing the Nebulizer Cup upright on the towel (See Figure F).
(Figure F)
Instructions For Use Figure F (0d806a34 E83d 4ce4 9da2 1630c49790a8 09)
Step 9: Connect one end of the tubing to the compressor air outlet (See Figure G). The tubing should fit tightly.
(Figure G)
Instructions For Use Figure G (0d806a34 E83d 4ce4 9da2 1630c49790a8 10)
Step 10: Plug in your compressor to an electrical outlet (See Figure H).
(Figure H)
Instructions For Use Figure H (0d806a34 E83d 4ce4 9da2 1630c49790a8 11)
Step 11: Open the tobramycin inhalation solution ampule by holding the bottom tab with 1 hand and twisting off the top of the tobramycin inhalation solution ampule with the other hand (See Figure I). Be careful not to squeeze the tobramycin inhalation solution ampule until you are ready to empty all the medicine into the Nebulizer Cup.
(Figure I)
Instructions For Use Figure I (0d806a34 E83d 4ce4 9da2 1630c49790a8 12)
Step 12: Squeeze all the medicine of the tobramycin inhalation solution ampule into the Nebulizer Cup (See Figure J).
(Figure J)
Instructions For Use Figure J (0d806a34 E83d 4ce4 9da2 1630c49790a8 13)
Step 13: Replace the Nebulizer Top. To replace the Nebulizer Top insert the Nebulizer Top into the Nebulizer Cup with the semi-circle halfway down the stem of the Nebulizer Top facing the Nebulizer Outlet. Turn the Nebulizer Top clockwise until securely fastened to the nebulizer Cup. (See Figure K).
(Figure K)
Instructions For Use Figure K (0d806a34 E83d 4ce4 9da2 1630c49790a8 14)
Step 14: Push the Mouthpiece straight onto the Nebulizer Outlet (See Figure L).
(Figure L)
Instructions For Use Figure L (0d806a34 E83d 4ce4 9da2 1630c49790a8 15)
Step 15: Firmly push the Inspiratory Valve Cap straight down onto the Nebulizer Top (See Figure M). The Inspiratory Valve Cap will fit tightly.
(Figure M)
Instructions For Use Figure M (0d806a34 E83d 4ce4 9da2 1630c49790a8 16)
Step 16: Hold the Nebulizer Cup upright and firmly push the free end of the tubing from the compressor to the Air Intake on the bottom of the Nebulizer Cup (See Figure N). Make sure to keep the Nebulizer Cup upright.
(Figure N)
Instructions For Use Figure N (0d806a34 E83d 4ce4 9da2 1630c49790a8 17)
Giving your Tobramycin Inhalation Solution Inhalation Therapy
Step 17: Turn on the compressor (See Figure O).
(Figure O)
Instructions For Use Figure O (0d806a34 E83d 4ce4 9da2 1630c49790a8 18)
Step 18: Check for a steady mist from the Mouthpiece (See Figure P). If there is no mist, check all tubing connections and make sure that the compressor is working properly.
(Figure P)
Instructions For Use Figure P (0d806a34 E83d 4ce4 9da2 1630c49790a8 19)
Step 19: Sit or stand in an upright position that will allow you to breathe normally. Place the Mouthpiece between your teeth and on top of your tongue and breathe normally only through your mouth (See Figure Q). Nose clips may help you breathe through your mouth and not through your nose. Do not block the airflow with your tongue.
(Figure Q)
Instructions For Use Figure Q (0d806a34 E83d 4ce4 9da2 1630c49790a8 20)
Step 20: Keep breathing in your tobramycin inhalation solution medicine for at least 15 minutes to get your full dose. Continue therapy until all your tobramycin inhalation solution medicine is gone, and there is no longer any mist being made. You may hear a sputtering sound coming from the Mouthpiece when the Nebulizer Cup is empty. The entire tobramycin inhalation solution therapy should take about 15 minutes to complete.
If you are interrupted, need to cough or rest during your tobramycin inhalation solution treatment, turn off the compressor to save your medicine. Turn the compressor back on when you are ready to restart your treatment.
Follow the nebulizer cleaning and disinfecting instructions after completing your therapy.
After your Tobramycin Inhalation Solution Inhalation Therapy
Cleaning Your Nebulizer
To reduce the risk of infection, illness or injury from contamination, you must thoroughly clean all parts of the nebulizer as instructed after each treatment. Never use a nebulizer with a clogged nozzle. If the nozzle is clogged, no aerosol mist is made, and your therapy will not be as effective. Replace the nebulizer if clogging occurs.
1) Remove tubing from nebulizer and disassemble nebulizer parts.
2) Wash all parts (except tubing) with warm water and liquid dish soap.
3) Rinse thoroughly with warm water and shake out water.
4) Air dry or hand dry nebulizer parts on a clean, lint-free cloth. Reassemble nebulizer when dry, and store. You can also wash all parts of the nebulizer in a dishwasher (except tubing).
1) Place the nebulizer parts in a dishwasher basket.
2) Place the dishwasher basket on the top rack of the dishwasher.
3) Remove and dry the parts when the cycle is complete.
Disinfecting Your Nebulizer
Your nebulizer is for your use only. Do not share your nebulizer with other people. You must disinfect the nebulizer every other treatment day. Failure to disinfect the nebulizer every other treatment day could lead to serious or fatal illness.
Clean the nebulizer as described above. Every other treatment day, disinfect the nebulizer parts (except tubing) by boiling them in water for a full 10 minutes. Dry parts on a clean, lint-free cloth.
Care and Use of Your Pulmo-Aide Compressor
Follow the manufacturer instructions for care and use of your compressor.
Filter Change:
